| General |
| Device Type |
Switch – 24 ports – L3 – managed – stackable – with 5 x Cisco Access Point Adder License (LIC-CTIOS-1A) |
| Enclosure Type |
Desktop, rack-mountable 1U |
| Subtype |
Gigabit Ethernet |
| Ports |
24 x 1/2.5/5/10GBase-T (UPOE) |
| Power Over Ethernet (PoE) |
UPOE |
| PoE Budget |
580 W |
| Performance |
Switching capacity: 640 Gbps ¦ Stacking bandwidth: 480 Gbps ¦ Forwarding performance: 500 Mpps |
| Capacity |
IPv4 routes: 24000 ¦ NetFlow entries: 24000 ¦ Switched virtual interfaces (SVIs): 1000 ¦ Virtual interfaces (VLANs): 4000 ¦ QoS hardware queues per port: 8 |
| MAC Address Table Size |
32000 entries |
| Jumbo Frame Support |
9198 bytes |
| Routing Protocol |
OSPF, BGP-4, IS-IS, RIP-1, RIP-2, EIGRP, IGMPv2, IGMP, PIM-SM, static IP routing, PIM-DM, IGMPv3, EIGRP for IPv6, OSPFv3, policy-based routing (PBR), RIPng, MLDv2, MLD |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, CLI |
| Authentication Method |
Kerberos, Secure Shell (SSH), RADIUS, Radio Service Set ID (SSID), TACACS+ |
| Features |
DHCP support, ARP support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, Intrusion Detection System (IDS), IPv6 support, Stateful switchover (SSO), PIM snooping, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Virtual Route Forwarding-Lite (VRF-Lite), Dynamic ARP Inspection (DAI), Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Port Security, Remote Switch Port Analyzer (RSPAN), CAPWAP support, Energy Efficient Ethernet, Management Information Base (MIB), Virtual Routing and Forwarding (VRF), Wireless Intrusion Prevention System (WIPS), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), 802.1x authentication, DiffServ Code Point (DSCP) support, radio resource management (RRM), IP source guard, Weighted Tail Drop (WTD), VLAN Trunking Protocol (VTP), Bridge protocol data unit (BPDU), Control plane protection (CoPP) |
| Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at |
| RAM |
4 GB |
| Flash Memory |
2 GB |
| Status Indicators |
Port transmission speed, port duplex mode, power, system, active, status, PoE |
| Expansion / Connectivity |
| Interfaces |
24 x 1/2.5/5/10GBase-T RJ-45 UPOE – 60 W ¦ 1 x USB Type A ¦ 1 x management (mini-USB) Type B ¦ 1 x console RJ-45 management ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 2 x network stack device |
| Expansion Slots |
1 (total) / 1 (free) x expansion slot |
| Power |
| Power Device |
Internal power supply |
| Installed Qty |
1 (installed) / 2 (max) |
| Power Redundancy |
Optional |
| Power Redundancy Scheme |
1+1 (with optional power supply) |
| Power Provided |
1100 Watt |
| Voltage Required |
AC 120/230 V (50 – 60 Hz) |
| Miscellaneous |
| Cables Included |
1 x stacking cable |
| MTBF |
203,150 hours |
| Compliant Standards |
CISPR 22 Class A, CISPR 24, EN 61000-3-2, NOM, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, UL 60950-1 Second Edition, KCC, RoHS, FCC Part 15 A, AS/NZS 3548 Class A, BSMI Class A, CAN/CSA C22.2 No. 60950-1, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN24, KN22 Class A, EN 300386, AS/NZS CISPR 22, CNS 13438, EN 55022 Class A |
| Software / System Requirements |
| Software Included |
Cisco IOS IP Base |
| Dimensions & Weight |
| Width |
17.5 in |
| Depth |
19.2 in |
| Height |
1.8 in |
| Weight |
17.64 lbs |
| Manufacturer Warranty |
| Service & Support |
Limited warranty – advance hardware replacement – lifetime – response time: next business day ¦ Technical support – consulting – 90 days |
| Environmental Parameters |
| Min Operating Temperature |
23 °F |
| Max Operating Temperature |
113 °F |
| Humidity Range Operating |
10 – 95% (non-condensing) |
| Min Storage Temperature |
-40 °F |
| Max Storage Temperature |
158 °F |
