| WS-C2960X-48LPD-L Specification |
| Enclosure type |
Rack-mountable – 1U |
| Ports |
48 x 10/100/1000 + 2 x 10G SFP+ |
| Network management Interface |
10/100 Mbps Ethernet (RJ-45) |
| Available PoE Power |
370W |
| Forwarding bandwidth(Gbps) |
108Gbps |
| Maximum stacking number |
8 |
| Stack Bandwidth |
80 G |
| Forwarding Performance |
130.9Mpps |
| Switching bandwidth |
216Gbps |
| Maximum active VLANs |
1023 |
| MAC Address Table Size |
16K (default) |
| CPU |
APM86392 600MHz dual core |
| RAM |
256 MB |
| Flash Memory |
64 MB |
| Status Indicators |
Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, PoE, and link speed |
| Expansion / Connectivity |
| Console ports |
USB (Type-B), Ethernet (RJ-45) |
| Stacking cable |
Optional |
| Power Redundancy |
Option (PWR-RPS2300) |
| Voltage range (Auto) |
110V-240V |
| Power Consumption Operational |
0.48KVA |
| Miscellaneous |
| Width |
17.5 Inches (44.5 cm) |
| Depth |
14.5 Inches (36.8 cm) |
| Height |
1.75 Inches (4.5 cm) |
| Weight |
12.9 lb (5.9 Kg) |
| Package Weight |
23.48 lb (10.65 Kg) |
| Rack Mounting Kit |
optional |
| MTBF in hours |
277,960 |
| Compliant Standards |
● IEEE 802.1D Spanning Tree Protocol
● IEEE 802.1p CoS Prioritization
● IEEE 802.1Q VLAN
● IEEE 802.1s
● IEEE 802.1w
● IEEE 802.1X
● IEEE 802.1ab (LLDP)
● IEEE 802.3ad
● IEEE 802.3af and IEEE 802.3at
● IEEE 802.3ah (100BASE-X single/multimode fiber only)
● IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports● IEEE 802.3 10BASE-T
● IEEE 802.3u 100BASE-TX
● IEEE 802.3ab 1000BASE-T
● IEEE 802.3z 1000BASE-X
● RMON I and II standards
● SNMP v1, v2c, and v3
● IEEE 802.3az
● IEEE 802.1ax |
| System software / license |
| System software |
IOS LAN BASE |
| license |
NERGY-MGT-100-K9, EW-DO-100-DE |
| features |
●Jumbo Frames
●VLANS
●Voice Vlan
●VTPv2
●CDPv2
●LLDP
●802.3ad LACP
●PVST/PVST+
●802.1W/802.1S
●Port Fast/Uplink Fast
●port CoS Trust and Override
●Scheduling
●Priority Queuing
●Configure CoS Priority Queues
●Weighted Tail Drop
●DSCP transparency |
| Network security |
●SSH, SSL and SCP
●RADIUS and TACACS+
●SNMPv3 crypto
●802.1x
●802.1x Accounting / MIB
●802.1x w/ port security
●802.1x w/Voice VLAN
●802.1x Guest VLAN
●802.1x VLAN assignment
●802.1x MAC-Auth Bypass
●BPDU/Root Guard
●Port Security
●Private VALN Edge
●Storm Control
●Block unknown unicast and multicast
●IGMP Snooping
●IGMP Filter/Throttle |
| Management and Troubleshooting |
●Auto-MDOX
●TDR
●UDLD
●IP SLA Responder
●layer 2 / IP Traceroute
●SPAN
●RSPAN
●Express Setup
●Device Manager
●Cisco Network Assistant
●Smartports + Advisor
●Troubleshooting Advisor
●Drag-and-drop Cisco IOS Upgrade
●IP Address DHCP
●Autoinstall with saved configuration
●Configuration Replace
●DHCP Auto Image Upgrade
●DHCP Port Based Allocation
●Error Disable MIB |
| Environmental Ranges |
| Operating temperature up to 5000 ft (1500 m) |
23ºF to 113ºF
(-5ºC to 45ºC) |
| Operating temperature up to 10,000 ft (3000 m) |
23ºF to 104ºF
(-5ºC to 40ºC) |
| Short-term exception at sea level* |
23ºF to 131ºF
(-5ºC to 55ºC) |
| Short-term exception up to 5000 feet (1500 m)* |
23ºF to 122ºF
(-5ºC to 50ºC) |
| Short-term exception up to 10,000 feet (3000 m)* |
23ºF to 113ºF
(-5ºC to 45ºC) |
| Short-term exception up to 13,000 feet (4000 m)* |
23º to 104ºF
(-5ºC to 40ºC) |
| Storage temperature up to 15,000 feet (4573 m) |
-13º to 158ºF
(-25º to 70ºC) |
| Operating altitude |
Up to 10,000 Feet
(Up to 3000 Meters) |
| Storage altitude |
Up to 13,000
(Up to 4000 Meters) |
| Operating relative humidity |
10% to 95% noncondensing |
| Storage relative humidity |
10% to 95% noncondensing |
